$45.00
These unique tapes were designed specifically for silicon wafer shipping boxes. Operators will like the easy release from the roll; ease of handling, low static charge on unwinds and excellent conformability around wafer box corners. Following our clean manufacturing process, each roll is individually wrapped in cleanroom polyethylene bags; and then double bagged in packs. Included in Sample Kit are UltraTape 1110, 1112, 1114, 1153, and 1164.
ITEM: #Semiconductor Tape Sample Kit (Wafer Box Sealing)
Price Per Pack: $45
QTY
UltraTape’s semiconductor cleanroom tapes are designed specifically for use inside semiconductor and critical environment cleanrooms. Operators will like the easy release from the roll, ease of handling, low static charge on unwind, and excellent conformability.
| Part # | 1110 | 1112 | 1114 | 1153 | 1164 |
| Backing | Polyethylene | Polyethylene | Polyethylene | Polyethylene | Polyolefin |
| Adhesive | Acrylic | Acrylic | Acrylic | Rubber | Acrylic |
| Total Thickness | 5.5 +/-0.7 mil |
5.5+/-0.7 mil |
5.5+/-0.7 mil |
7.0+/-1.0 mil | 4.3+/-0.5 mil |
| Adhesion to Stainless Steel | 56oz/inch | 30oz/inch | 12oz/inch | 60oz/inch | 36oz/inch |
| Operating Temperature | -20° to +190° F | -40° to +250° F |
-20° to +190° F |
-20° to +200° F | -40° to 190° F |
| Elongation at Break | 450% | 550% | 450% | 80% | 650% |
| Tensile Strength | 12lbs/inch | 14lbs/inch | 9lbs/inch | 15lbs/inch | 15lbs/inch |
| Length | 36 yards | 36 yards | 36 yards | 36 yards | 60 yards |
UltraTape 1110 is designed specifically for cleanroom packaging, wafer shipping boxes and bags. Specially formulated adhesive leaves no residue or ghosting on plastic boxes, even after prolonged storage. Extremely low levels of metals, halogens, and outgassing. Additional Product Specifications for 1110.
UltraTape 1112 is designed specifically for cleanroom packaging, wafer shipping boxes and bags. Specially formulated adhesive leaves no residue or ghosting on plastic boxes, even after prolonged storage. Extremely low levels of metals, halogens, and outgassing. Additional Product Specifications for 1112.
UltraTape 1114 is a low tack version of the 1110 and 1112 cleanroom packaging product. It also works well for other applications in your cleanroom where removability is necessary after short term or long term applications. Additional Product Specifications for 1114.
UltraTape 1153 is ideal for any application needing a strong hold. The rubber adhesive bonds quickly to most surfaces and s considered low residue for glass, metal, and plastic. A good replacement for vinyl tape in cleanroom environments. Additional Product Specifications for 1153.
UltraTape 1164 is a zero residue cleanroom tape that looks and performs like vinyl tape, yet has much lower metals, is lead-free, and environmentally superior. It has low stretch and is removable from all surfaces. UltraTape’s high purity medium adhesion tape has a very easy release from the roll and is excellent for sealing bags, taping wafer boxes, sealing garment cuffs, taping signs to walls and equipment and general cleanroom production and maintenance use. 1164 is excellent for long term applications. Additional Product Specifications for 1164.
